项目中,需要使用到动态图标,发现又好用的库,在这里分享一下,需要使用的工具库为lottie-react-native,通过导出
一、Lottie是什么?
Lottie是Airbnb开源的一个支持 Android、iOS 以及 ReactNative,利用Json文件的方式快速实现动画效果的库。简单点说就是Json文件记录动画路径,Android、iOS 以及 ReactNative解析展现出来。
二、Lottie能实现什么效果?
三、集成过程
1.安装拉取第三方包:
1 2 | yarn add lottie-react-native yarn add [email protected] |
or
1 2 | npm i --save lottie-react-native npm i --save [email protected] |
如果是ios平台,请继续执行下面命令(react-native 版本大于0.60或更高的不需要手动react-native link,而是通过pod install安装依赖):
1 | cd ios && pod install |
至此,就完成了第三方包的引入工作。
??:Android平台不需要特殊处理,除非报错崩溃了,请检查以下位置:
a.路径
在顶部导入,添加
1 | import com.airbnb.android.react.lottie.LottiePackage; |
在 List getPackages();中,添加
1 | packages.add(new LottiePackage()); |
b.路径
1 | implementation project(':lottie-react-native') |
c.路径
1 2 | include ':lottie-react-native' project(':lottie-react-native').projectDir = new File(rootProject.projectDir, '../node_modules/lottie-react-native/src/android') |
2.获取json文件
这个使用的json文件,是由Adobe After Effects这个软件生成,然后通过其插件bodymovin 生成,同时这里有安装教程,具体导出过程烦请请教UI设计,他们可能会更熟悉。如果实在找不到了,就使用这里的json文件->文件地址
3.组件库的使用
假设我们已经获取到这个animation.json文件了,如下所示最基础的使用方法:
1 2 3 4 5 6 7 8 | import React from 'react'; import LottieView from 'lottie-react-native'; export default class BasicExample extends React.Component { render() { return <LottieView source={require('./animation.json')} autoPlay loop />; } } |
当然,还有其他接口提供使用
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 | import React from 'react'; import LottieView from 'lottie-react-native'; export default class BasicExample extends React.Component { componentDidMount() { // 手动控制播放 this.animation.play(); // 设置特定的开始时间和结束时间 this.animation.play(30, 120); } render() { return ( <LottieView ref={animation => { this.animation = animation; }} source={require('../path/to/animation.json')} /> ); } } |
结合react-native组件Animated实现控制动画播放的过程
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 | import React from 'react'; import { Animated, Easing } from 'react-native'; import LottieView from 'lottie-react-native'; export default class BasicExample extends React.Component { constructor(props) { super(props); this.state = { progress: new Animated.Value(0), }; } componentDidMount() { Animated.timing(this.state.progress, { toValue: 1, duration: 5000, easing: Easing.linear, }).start(); } render() { return ( <LottieView source={require('../path/to/animation.json')} progress={this.state.progress} /> ); } } |
还能够指定的更改图层的颜色
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 | import React from 'react'; import LottieView from 'lottie-react-native'; export default class BasicExample extends React.Component { render() { return ( <LottieView source={require('../path/to/animation.json')} colorFilters={[{ keypath: "button", color: "#F00000" },{ keypath: "Sending Loader", color: "#F00000" }]} autoPlay loop /> ); } } |
Component API:
Prop | Description | Default |
---|---|---|
Mandatory - The source of animation. Can be referenced as a local asset by a string, or remotely with an object with a |
None | |
A number between 0 and 1, or an |
||
The speed the animation will progress. Sending a negative value will reverse the animation | ||
The duration of the animation in ms. Takes precedence over |
||
A boolean flag indicating whether or not the animation should loop. | ||
A boolean flag indicating whether or not the animation should start automatically when mounted. This only affects the imperative API. | ||
A boolean flag indicating whether or not the animation should size itself automatically according to the width in the animation’s JSON. This only works when |
||
Style attributes for the view, as expected in a standard |
None | |
Needed for Android to work properly with assets, iOS will ignore it. | None | |
A callback function which will be called when animation is finished. Note that this callback will be called only when |
None |
Methods (Imperative API):
Method | Description |
---|---|
Play the animation all the way through, at the speed specified as a prop. It can also play a section of the animation when called as |
|
Reset the animation back to |
更多的接口可以参见:接口参见
四、集成效果图
五、可能遇到的问题
1.Undefined symbol: protocol xxx
解决方案:
1.在Xcode中打开ios / YourAppName.xcodeproj
2.在左侧的项目浏览器中,右键单击您的应用程序名称,然后单击新建文件…。 为项目创建一个空的Swift文件(添加时请确保选择了target是“您的应用名称”)
3.当Xcode询问时,按Create Bridging Header,然后不要删除Swift文件。重新运行您的构建。
参考地址:
1.https://github.com/mxcl/PromiseKit/issues/1059
2.https://stackoverflow.com/questions/57903395/about-100-error-in-xcode-undefined-symbols-for-architecture-x86-64-upgraded-re
